Cylinder diameter**: 20mm - 80mm (customizable) - 20mm standard cylinder is suitable for light equipment;
- 40mm reinforced cylinder meets the needs of medium-sized machinery;
- 60-80mm heavy-duty cylinder is specially designed for mining machinery and port equipment;
- Inner wall nano-coating technology reduces friction loss and extends service life.
Our industrial gas springs are designed for industrial scenarios such as automation equipment, heavy mechanical doors, storage systems and production lines. They use high-strength materials and precision manufacturing processes to provide excellent load capacity and long-term stability. Whether it is high-frequency operation, extreme temperature environment or high-impact working conditions, this gas spring can maintain reliable performance and help industrial equipment improve efficiency and safety.
Force adjust | Adjustable force range: 200N - 5000N (customizable) - 200N - 1000N (lightweight robotic arms, control panels, small equipment doors) - 1000N - 3000N (medium-sized conveyor belt doors, automated fixtures, hydraulic devices) - 3000N - 5000N (heavy-duty mechanical doors, lifting platforms, industrial valves) |
Tool-free dynamic adjustment, supporting real-time load calibration; - Digital scale display and mechanical locking dual system to ensure precise control. | |
Material | Cylinder material**: - High-strength 7075 aluminum alloy or 42CrMo alloy steel, compressive strength increased by 30%; - Deep anodizing + ceramic coating, acid and alkali corrosion resistance, adaptable to chemical plant environment. |
Piston rod material**: - 40CrNiMoA chrome-plated steel, surface hardness HRC60 or above; - Coating thickness ≥30μm, anti-wear life increased by 50%; - Salt spray test 1000 hours, meet the needs of marine engineering. | |
| Sealing material: high-quality fluororubber or polyurethane, effectively preventing dust and dirt from entering the gas spring, ensuring sealing and long-term use. | |
Operating Conditions | Temperature range**: -50℃ to +200℃; - Internal inert gas ratio, no freezing at low temperature and no expansion leakage at high temperature. |
Anti-seismic performance**: - Stable operation under continuous vibration frequency of 0-200Hz and amplitude of ±5mm; - No performance degradation after 100,000 impact tests. | |
Weather resistance Relative humidity 0-95% all-weather operation IPX5 waterproof level, to cope with the wading environment of the campsite Salt spray test 500 hours, to meet the needs of seaside campsites. | |
Service life**: - Dynamic fatigue test 500,000 cycles; - Extreme temperature alternation test 1,000 times; - Average opening and closing times 5,000 times per day, service life ≥ 5 years. |
Installation
● End fittings: Standard M8/M6 quick-release connectors
Optional extended connectors to accommodate thickened panels on toy box lids
Anti-loosening thread design
● Installation method: quick connection or bolt connection, easy to install.
Safety Features
● Overload protection**:
- Automatic locking when overloaded by 10% to prevent damage to the mechanical structure;
- Emergency manual release function to ensure maintenance safety.
● Failure-proof design**:
- Dual redundant gas system, basic functions can be maintained even if a single gas line fails;
- Automatically lock when gas is cut off to prevent the equipment from falling accidentally
Specification
● Cylinder diameter**: 20mm - 80mm (customizable)
- 20mm standard cylinder is suitable for light equipment;
- 40mm reinforced cylinder meets the needs of medium-sized machinery;
- 60-80mm heavy-duty cylinder is specially designed for mining machinery and port equipment;
- Inner wall nano-coating technology reduces friction loss and extends service life.
● Piston rod diameter**: 10mm - 25mm (customizable)
- 10mm standard type, load-bearing range 500-2000N;
- 16mm reinforced type, suitable for heavy loads above 3000N;
- 25mm super heavy type, meeting the needs of extreme industrial environments.
● Stroke length**: 50mm - 1500mm (customizable)
- Short stroke (50-200mm): precision instrument positioning;
- Standard stroke (200-800mm): general industrial equipment;
- Extra long stroke (800-1500mm): large lifting platforms, storage shelves.
Surface Coating
● Surface treatment: hard chrome plating, excellent wear resistance, capable of frequent lifting and lowering
● Available in matte, glossy or custom finishes.
Performance
Two-way shock-absorbing structure effectively reduces the impact of bumps on the toy box cover
Special anti-rust, to cope with high humidity environment such as tide
Noise reduction design to eliminate opening and closing noise at night.
Certification
Industrial applications require compliance with ISO 9001 or industry-specific standards (e.g. TS 16949 for the automotive industry)
● RoHS: Complies with environmental safety requirements, will not release harmful gases during long-term use, and protects the air quality in the car
● SGS: Independent product testing and verification, precise and controllable opening and closing force, easy and smooth operation
Customization options
● Customized options: Customized installation interface, providing a variety of standard joint options (ball head/fork head/eye head) Supports customized special joints, perfectly matching the original installation position
● Customized opening force, accurately calculate the required force according to the weight and size of the door panel, ensuring easy opening with one hand while maintaining a stable opening state
● Customized functional characteristics, optional anti-smashing rebound buffer function, customized safety design with limit protection
● Customized surface treatment and customized colors to perfectly match the car body
Automated production line
The robot arm is precisely positioned to reduce downtime.
Heavy duty mechanical door
Smooth opening and closing of mining equipment and port gates.
Warehousing logistics system
The shelves can be lifted and lowered smoothly, and can carry more than 2 tons of goods.
Energy equipment
Nuclear power valve control, wind power blade locking.
Rail Transit
High-speed rail cabin doors are cushioned to reduce impact noise.
Innovative Design: Our dedicated R&D team specializes in developing innovative gas springs for toy box lids that provide smooth operation, precise force control, and enhanced durability.Continuous Improvement: We incorporate customer feedback into our product development process to provide solutions that meet changing market demands.
Cost-effective solutions: We optimize production processes to offer competitive prices without compromising quality.Fast delivery: With an automated production capacity of up to 80,000 gas springs per day, we ensure timely delivery to meet tight deadlines.
