● Adjustable from 50mm – 1000mm (custom sizes available)
Affects the total movement range
● Common sizes: 22mm – 40mm (tube), 8mm – 14mm (rod)
Stronger materials for durability in industrial environments
● Ball joints, Eyelets, Clevis brackets, Threaded ends
Custom mounting options for specialized factory applications
A Factory Lift Gas Spring is a high-performance nitrogen-filled device designed to provide lifting assistance, controlled motion, and damping for industrial and factory applications. These gas springs help reduce manual effort, improve operational efficiency, and ensure smooth and controlled lifting and lowering of heavy machinery, access panels, and storage compartments.
Force range | Available in 500N – 5000N or more for factory-grade lifting Determines the weight it can lift and hold securely. |
Material | Cylinder body: steel (galvanized or sprayed) or stainless steel (corrosion resistant).Piston rod: hard chrome plated steel or stainless steel. |
Sealing material: high-quality fluororubber or polyurethane, effectively preventing dust and dirt from entering the gas spring, ensuring sealing and long-term use. | |
Operating Conditions | Applicable temperature range:Regular models: -20℃~+80℃; special models can withstand -40℃~+120℃. |
Installation
Distinguish between compression type (support force direction is consistent with installation direction) and tension type (reverse support)
Safety Features
Avoid using the machine at full stroke limit, and keep 10%~20% stroke margin to extend life. If frequent high-speed movement is required (such as a robotic arm), a high-response speed model should be selected.
Certification
Industrial applications require compliance with ISO 9001 or industry-specific standards (e.g. TS 16949 for the automotive industry)
● RoHS: Complies with environmental safety requirements, will not release harmful gases during long-term use, and protects the air quality in the car
● SGS: Independent product testing and verification, precise and controllable opening and closing force, easy and smooth operation
Customization options
● Customized options: Customized installation interface, providing a variety of standard joint options (ball head/fork head/eye head) Supports customized special joints, perfectly matching the original installation position
● Customized opening force, accurately calculate the required force according to the weight and size of the door panel, ensuring easy opening with one hand while maintaining a stable opening state
● Customized functional characteristics, optional anti-smashing rebound buffer function, customized safety design with limit protection
● Customized surface treatment and customized colors to perfectly match the car body
Industrial Furniture & Workstations
Height-adjustable workbenches and tables.
Medical & Laboratory Equipment
Adjustable hospital beds and operating tables.
Coated for protection against rust and wear.
Available in various sizes and pressure ratings.
Compatible with different end fittings and brackets.
