Our small gas springs are designed for toy box lids, providing perfect support and durability, ensuring smooth and stable opening and closing of children's toy box lids. Whether for daily use or long-term storage, our gas springs can meet high-intensity use requirements and strictly comply with international safety standards. We are committed to providing you with customized solutions that meet the latest industry regulations, safety requirements and quality standards, helping you improve the competitiveness of your products and customer satisfaction.
Our small gas springs are designed for toy box lids, providing perfect support and durability, ensuring smooth and stable opening and closing of children's toy box lids. Whether for daily use or long-term storage, our gas springs can meet high-intensity use requirements and strictly comply with international safety standards. We are committed to providing you with customized solutions that meet the latest industry regulations, safety requirements and quality standards, helping you improve the competitiveness of your products and customer satisfaction.
Force adjust | Adjustable force range**: 20N - 800N (customizable) - 20N - 100N (small tool box cover, light drawer) - 100N - 300N (medium tool box folding stand, multi-layer drawer system) - 300N - 800N (heavy industrial tool box cover, tool cabinet lift door) Tool-free dynamic adjustment, supporting real-time load calibration; - Digital scale display and mechanical locking dual system to ensure precise control. |
Material | Cylinder material**: - 6061-T6 aluminum alloy, lightweight design reduces overall weight; - Hard anodized, scratch-resistant, corrosion-resistant, suitable for oily workshop environment. |
Piston rod material**:- 304 stainless steel + chrome plating process, surface hardness HV800; - Salt spray test for 300 hours, excellent anti-rust performance; - Precision grinding process, seal life increased by 40%. | |
Operating Conditions | Temperature range**: -30℃ to +120℃; - Low temperature anti-freezing design, high temperature anti-expansion leakage design. |
| Anti-seismic performance**: - Stabl operation at continuous vibration frequency of 0-50Hz and amplitude of ±3mm; - No performance degradation after 50,000 impact tests. | |
Weather resistance Relative humidity 0-95% all-weather operation IPX5 waterproof level, to cope with the wading environment of the campsite Salt spray test 500 hours, to meet the needs of seaside campsites | |
Service life**: - Dynamic fatigue test 200,000 cycles; - Average opening and closing times 1,000 times per day, service life ≥ 8 years. |
Specification
●Cylinder diameter**: 10mm - 25mm (customizable)
- 10mm ultra-thin cylinder, suitable for compact tool boxes;
- 15mm standard cylinder, meeting the needs of general tool boxes;
- 20-25mm reinforced cylinder, specially designed for heavy-duty tool cabinets;
- Inner wall polishing process, friction is reduced by 30%, and opening and closing is smoother.
● Piston rod diameter**: 4mm - 8mm (customizable)
- 4mm slim piston rod, suitable for installation in small spaces;
- 6mm standard type, load-bearing range 50-200N;
- 8mm reinforced type, suitable for load scenarios above 500N.
● Stroke length**: 50mm - 300mm (customizable)
- Short stroke (50-100mm): small tool box cover;
- Medium stroke (100-200mm): multi-layer drawer support;
- Long stroke (200-300mm): folding bracket unfolded and locked.
Surface coating
● Surface treatment: hard chrome plating, excellent wear resistance, capable of frequent lifting and lowering.
● Available in matte, glossy or custom finishes.
Installation
● End fittings: Standard M8/M6 quick-release connectors
Optional extended connectors to accommodate thickened panels on toy box lids
Anti-loosening thread design
● Installation method: quick connection or bolt connection, easy to install
Performance
● Two-way shock-absorbing structure effectively reduces the impact of bumps on the toy box cover.
● Special anti-rust, to cope with high humidity environment such as tide.
● Noise reduction design to eliminate opening and closing noise at night.
Safety Features
●Overload protection**:
- Automatic locking when overloaded by 15% to protect the tool cabinet structure;
- Emergency manual pressure relief valve for easy maintenance operations.
●Anti-pinching design**:
- Closing speed ≤ 0.5m/s to avoid accidental pinching;
- Automatic rebound function when encountering resistance, with adjustable sensitivity.
Certification
Industrial applications require compliance with ISO 9001 or industry-specific standards (e.g. TS 16949 for the automotive industry)
● RoHS: Complies with environmental safety requirements, will not release harmful gases during long-term use, and protects the air quality in the car
● SGS: Independent product testing and verification, precise and controllable opening and closing force, easy and smooth operation
Customization options
● Customized options: Customized installation interface, providing a variety of standard joint options (ball head/fork head/eye head) Supports customized special joints, perfectly matching the original installation position
● Customized opening force, accurately calculate the required force according to the weight and size of the door panel, ensuring easy opening with one hand while maintaining a stable opening state
● Customized functional characteristics, optional anti-smashing rebound buffer function, customized safety design with limit protection
● Customized surface treatment and customized colors to perfectly match the car body
Tool box cover
Open and close easily with one hand, stable support without shaking
Multi-layer drawer system
Smooth pulling and even load-bearing without jamming
Folding workbench stand
One-touch unfolding and locking, strong support
Mobile tool cabinet door
Heavy-duty door panels rise and fall smoothly to prevent accidental falls
Outdoor tool box
Waterproof and rust-proof design, suitable for harsh environments
Innovative Design: Our dedicated R&D team specializes in developing innovative gas springs for toy box lids that provide smooth operation, precise force control, and enhanced durability.Continuous Improvement: We incorporate customer feedback into our product development process to provide solutions that meet changing market demands.
Tailor-made solutions: We offer fully customizable options tailored to vehicle size standards in different countries.Flexible OEM/ODM service: Our team works closely with customers to design and manufacture products that meet the usage habits of the target market.
Export Experience: We export gas springs for toy box lids to customers around the world, including North America, Europe and Asia, with a strong reputation for reliability and performance.Trusted by Industry Leaders: Our products are used by renowned companies in the automotive, furniture and industrial sectors.
